In addition to the primary output, there is a charger output with a smaller rated current, enabling backup power supply applications for security access systems. With a rated efficiency of 86%, it can operate with air convection cooling in temperatures from -30 to 70 degress Celsius. Key protection features include over-temperature, over-voltage, battery low cut off, and battery reverse polarity protection (by fuse).

Output Voltage: 13.8VDC

Current: 1.9A/1A

Power: 40W

Ripple Voltage: 120mV p-p

Input Voltage: 90-264VAC

Input Frequency: 47-63Hz

Inrush Current: 30A@115VAC, 60A@230VAC
