PSU DIN ENC 30W 12VDC 2A
Code: 8199864
Mean Well HDR-30-12 DIN Rail Power Supply, 30W, 12V, 2A Output - Model MP3156
This power supply offers a 3-year warranty and is part of the Mean Well HDR series, available in 15W, 30W, and 60W options. It features an ultra-slim, step-shaped plastic housing, adhering to the European Union standard DIN EN43880. The design is compact with a height of 90mm and widths ranging from 1SU to 3SU (17.5mm/35mm/52.5mm). The unit boasts up to 91% efficiency, adjustable DC output voltage (±10%), and operates within a temperature range of -30°C to +70°C. Ideal for building automation, household control systems, industrial control systems, factory automation, and electro-mechanical apparatus.
Key Features:
- Ultra-slim design: 17.5mm (1SU) / 35mm (2SU) / 52.5mm (3SU) width
- Universal input: 85~264VAC
- Low power consumption: < 0.3W at no load
- Isolation class II
- LPS (Limited Power Source) compliant
- Adjustable DC output voltage
- Protections: short circuit, overload, over voltage
- Cooling: free air convection (operating temperature: -30°C to +70°C)
- DIN rail mountable: TS-35/7.5 or 15
- LED power indicator
- Input voltage: 85 ~ 264VAC, 120 ~ 370VDC
- Input frequency: 47 ~ 63Hz
- Cold start inrush current: 45A @ 230VAC
- DIN Rail Compatibility: TS35/7.5 or 15
Please note: DIN Rail is not included.
Please note: Prices are shown including GST (where applicable) and are in AUD$
