Specifications:

• Connector A: USB 3.2 Type C Male
• Connector B: USB 3.2 Type B Male
• Housing Material: PVC
• Connector Plating: Nickel
• Pin Construction: C: High conductivity copper
• B: Brass
• Pin Plating: Gold
• Dimensions: C: 10.8x32x7.8mm
• B: 12.2x46x10mm
• Length: 3m
• Standard: USB 3.2 Gen 1
• Type: Round
• Jacket Diameter: 4.3mm (0.17in)
• Jacket Material: PVC
• Conductor Material: Tinned Copper
• Conductor Gauge Power: 22AWG
• Conductor Gauge Data: 30AWG
• Shielding: Copper Braid 82%
• Shielding in connector headshell: Copper foil
• Supported Bandwidth: 5Gbps
• Nominal Attenuation: 100-2500MHz < 20db
• Minimum Band Radius: 25mm (0.98in)
• Operating Temperature: 0C - 40C
• Storage Temperature: 0C - 70C
• Packaging Type: Polybag
• Certificated: RoHS, REACH, California Proposition 65, UL
• Colour: Black
• Warranty: 10-year

Features:

• Professional choice USB 3.2 Gen 1 Type C to B cable for commercial and high-performance AV and IT installations
• SuperSpeed USB - supports data transfer speeds up to 5Gbps (USB 3.0, USB 3.1 Gen 1)
• Robust PVC housing, gold-plated contacts and nickel-plated connectors
• Triple-shielded cable, corrosion-resistant tinned copper conductors
• 10-year warranty
