CP OL3000VA RACK TOWER UPS
Code: 8217899
CP OL3000VA Rack Tower UPS
Specifications:
- Phase: Single Phase
- Form Factor: Rackmount / Tower
- UPS Topology: Online Double Conversion
- Energy Saving Technology: Online ECO Mode Efficiency
- Active PFC Compatibility: Yes
- Generator Compatibility: Yes
- Input Voltage Range: 190 - 300 Vac
- Input Frequency: 50 ± 10 - 60 ± 10Hz
- Rated Input Current: 15 A
- Input Power Factor: 0.99
- Input Connector Type: IEC C20
- Detachable Power Cord Plug Type: IEC C19 x 1
- Power Cord Length: 3m
- Capacity: 3000 VA / 2700 Watts
- Power Factor: 0.9
- Overload Protection: Internal Current Limiting, Circuit Breaker
- Overload Protection (Line Mode): 105-125% Load for 1 min, 125-150% Load for 10 sec
- Overload Protection (Battery Mode): 105-130% Load for 10 sec, 130-150% Load for 2 sec
- Harmonic Distortion (Linear Load): THD ? 3%
- Harmonic Distortion (Non-linear Load): THD ? 5%
- Internal Bypass: Automatic Bypass, Manual Bypass
- Total Outlets: 9
- Outlet Type: IEC C13 x 8
- IEC C19 x 1
- Battery & Surge Protected Outlets: 9
- Critical Load Outlets: 5
- Non-Critical Load Outlets: 4
- Typical Transfer Time: 0 ms
- Runtime at Half Load: 11 min
- Runtime at Full Load: 3 min
- Typical Recharge Time: 5 hours
- Start On Battery: Yes
- Smart Battery Management (SBM): Yes
- Hot-swappable: Yes
- Battery Cartridge: RBP
- Compatible Extended Battery Module: BPE72V60ART2US
- Max. EBM Quantity: 10 pcs
- Surge Suppression: 1335 Joules
- EMI/RFI Filtration: Yes
- SNMP/HTTP Remote Monitoring: Yes, with optional RMCARD205
- Enclosure Construction: Metal
- Rackmount Rail: Yes
- Rackmount Ears: Yes
- Dimensions: 433 x 88 x 600mm
- Weight: 32kg
- Audible Noise at 1.5M: 55 dBa
- Certifications: CE, BSMI, C-Tick, RoHS
- Warranty: 2 Years
Features:
- Online (Double Conversion) UPS Topology
- Generator Compatible
- Critical/Non-critical Load Outlets
- Smart Battery Management (SBM)
- Extended Battery Module (EBM)
- EMI and RFI Filtration
- LCD Status Display
- Emergency Power Off (EPO) Port
- SNMP/HTTP Remote Management Capability (Optional)
- ECO Mode
- Overload Protection
- Zero Transfer Time
- Hot-swappable Batteries
- Surge and Spike Protection
- Phone/Fax/Modem/DSL/Network Protection
- Detachable LCD Panel
- PowerPanel Management Software
- Rack/Tower Convertible Configurations
